Super Precision 3-Jaw Punch Former

Product NO: FT-PF550-SC40

¥590,000

This is a back-order item

Specification

●It offers a strong grip and excellent durability.
●The center hole is a through-hole.
●The FT-PF550-SC40 is an ultra-precision type with an accuracy of 0.003 mm.
●Equipped with dual bearings to provide exceptional stability and accuracy.
●The indexing function enables precise manufacturing of polygonal punches.

unit：mm

Product NOFT-PF550-SC40
Center height85±0.5ｍｍ
Indexer tooth q'ty & accuracy24、15°±10”
Through hole diametersØ30mm
inside diameterGripping rangeØ1-25ｍｍ
Outer diameterGripping rangeClamping Not Possible
Rotational accuracy0.003mm
Repeat accuracy0.003mm
weight（kg）8.5kg
