Magnetic Sine Bar

Material：SKS(Hardened and ground)

Hardness：HRC56°～60°

Parallelism: Within 0.002 mm

Squareness: Within 0.005 mm / 100mm

Center-to-center accuracy: ±0.002 mm

Angular deviation within 30 sec.

Collocate with gauge blocks for measuring workpiece’s angle.

●Equipped with a fine-adjustment mechanism

●Gauge blocks are not included.

●With magnetic base for easier fixation.
