Precision 3D Universal Vise

Features：The 3-Axis Precision Vice features a 360° horizontal rotation, a 45° vertical tilt, and an additional 45° lateral tilt, enabling absolute flexibility for complex 3D compound-angle positioning.
Material：Slewing unit FCD45/vice SKS3
Hardness：Slewing unit HRC43-47/ ViceHRC58-60
Heat Treatment: Quenched and tempered swivel base / Sub-zero treated vice body.
Swivel Assembly: Features a vernier scale with a 3-arcminute resolution for both horizontal rotation and vertical tilt angles.
Parallelism：within 0.004mm/100mm
Squareness：within 0.005mm/100mm
Inspection Certificate: Included
This ultra-precision 3-axis vice integrates a precision sine vice onto a robust swiveling and tilting base, enabling highly complex 3D compound-angle machining with sub-micron accuracy.
Equipped with a graduated scale for quick and easy angle adjustment.
(The sine vice is configured using precision gauge blocks and a trigonometric function table.)
Swivel Base: 360° horizontal rotation / 45° vertical tilt
Sine Vice Assembly: Max 45° tilt
Minimum Vernier Reading: 3 arcminutes
Storage Case: Included
